Why Choose Optiprime?

Our Solution combines cutting-edge innovation with operational excellence. Whether you require power for commercial, industrial, or hybrid applications, our Genset ensures maximum performance with minimal environmental impact. Organizations prioritizing sustainability and cost-efficiency will benefit from reduced emissions and optimized fuel consumption, ensuring reliable performance across all environments.

OPTIMUM POWER | OPTIMUM FOOTPRINT | OPTIMUM SAVING

Benefits

Compact Design
Achieve up to a 20% reduction in footprint, making it the ideal solution for sites with complex conditions and customers facing space constraints.
Optimal efficiency
Experience superior fuel efficiency that not only reduces operational costs but also accelerates CAPEX recovery in the shortest possible timeframe.
Flexibility
Tailored to support applications and customer needs where load conditions vary or demand flexibility, ensuring seamless and reliable performance.

CPCB IV+ Compliance
Advanced emission control technology significantly reduces environmental impact, aligning with the latest regulatory standards.

Ease of Use
Designed with intuitive control systems and simplified maintenance for hassle-free operation and management.

Technical Specification

		CPCB IV+  117 kVA	CPCB IV+ 400 kVA	CPCB IV+ 500 kVA	CPCB IV+ 640 kVA	CPCB IV+ 1000 kVA	CPCB IV+ 1500 kVA	2020 kVA (Containerized)
		(58.5×2) kVA	(200×2) kVA	(250×2) kVA	(320×2) kVA	(500×2) kVA	(750×2) kVA	(1010×2) kVA
Prime Rating at rated rpm (as per ISO8528)1	kVA	58.5 X2	200 X2	250 X2	320 X2	500 X2	750 X2	1010X2
	kW	46.8 X 2	160 X 2	200 X 2	256 X 2	400 X 2	600 X 2	808X2
Voltage (V)		415V
Frequency (Hz)		50 Hz
Power Factor		0.8 lagging
Noise level (dBA)		≤ 75 dBA (Genset with canopy)						Contact KOEL for details
Weight of Genset with canopy (approx.)$ {in Kg}	Dry	2511	6000	8000	8100	13786	18500	25170
	Wet	2561	6100	8150	8250	14000	18900	26000
Overall dimensions of Genset^ (mm)	Length	2900	7500	8500	8500	11200	12000	12192
	Width	2100	1450	1700	1700	2125	2300	2438
	Height (without silencer)	1701	1900	2042	2042	2655	2713	2895
	Height (with silencer)	1701	2730	2487	2487	3655	3381	4002
Genset alignment/configuration		Parallel	Series	Series	Series	Series	Series	Series
Engine Model		4R810ETA 4G1	6K1080ETA 4G2	6SL90ETA 4G2	6SL90ETA 4G3	DV8ETA 4G3	DV12ETA 4G2	DV16 ETA G3
Rated output (HP)		74X2	250X2	310X2	380X2	608X2	900.6X2	1210X2



2 X POWER: INNOVATION COMBINED WITH OPTIMAL EFFICIENECY

Optimum Power, Maximum Efficiency

Optiprime is designed to handle variable power demands with ease. The system’s auto load monitoring and sharing ensures balanced operation, minimizing fuel consumption and extending engine life.

Compact and Flexible Design

With single-package solution, it combines power redundancy, ease of handling, and transportation. This compact system is ideal for sites with limited space, ensuring no compromise on performance.



APPLICATION & SEGMENTS
