TECHNICAL SPECIFICATIONS
| Prime Rating at rated rpm (as per ISO8528)1 | kVA | 1010 HD | 1250 HD | 1500 HD | |
| kW | 808 | 1000 | 1200 | ||
| Genset Model | KG1-1010WS | KG1-1250WS | KG1-1500WS | ||
| Frequency | Hz | 50 | |||
| Power Factor | lagging | 0.8 | |||
| Voltage | V | 415 (3ɸ) | |||
| Noise level | dBA | Contact Kirloskar Oil Engines Ltd for Design | |||
| ✪ Weight of genset with canopy (approx..)^ | Dry | Kg | 13200 | 13075+ | |
| Overall dimensions of genset ^ | Length | mm | 7800 | 5650+ | |
| Width | mm | 2300 | 2300+ | ||
| Height | mm | 2713 | 2680+ | ||
| Engine Model | DV16ETA | 12K4300-E1 | 12K4300-E2 | ||
| Rated output | HP | 1210 | 1482 | 1760 | |
PRODUCT USP
• Prime rating and Stand-by rating.
• Best Efficiency at recommended average load.
• Genset Monitoring at Your Finger Tips.
• Less coolant required.
• Superior Blcok loading capacity for complex operation/ segment.
• Best in class CRDi System to improve fuel efficiency for 1010kva.
• V Type Engine Provide higher Torque at less RPM that will impact on overall.
• Performance Multistage oil filteration system.
• Electronic engine speed control.
• State of the art Genset Controller.
• Peace-of-mind Ownership.
• Compact footprint.
• Alternator Features: Kirloskar Alternator is compact in design, rugged and best in class efficiency
• Advanced Digital AVR improves the Voltage regulation and Response time.
• Better NVH.
• K-Oil Preminium ( Lube oil price is lesser than competition).
• Low Operation cost.
• Assemble canopy tranporation saving in installation time.
• Nodular cast iron block for ductivilty and strenghting.
• High pressure injection system , Edge molded gaskit technology for longer sealing life.
